900mm Laser Welded Circular Saw Concrete Blade For Cutting Prestressed Hollow Slab

Ask Latest Price
Video Channel
Brand Name :Johnson Tools
Model Number :YY
Certification :SGS,GB
Place of Origin :China
MOQ :5pcs
Price :Negotiate
Payment Terms :L/C, T/T, Western Union, Paypal
Supply Ability :500pcs monthly
Delivery Time :25-30days
Packaging Details :Plywood
Product Name :Diamond Circular Saw Blade
Suitable Machine :Elematic, Levanto, Ultraspan, Nord Impant, etc
Technology :Laser Welded
Outer Diameter :900mm
Segment Height :10/12/15mm
Slot Type and Width :Key Slot with Width 3mm
Center Hole :60mm or as your request
Application :Cutting Prestressed Concrete Hollow Slab
Package :Plywood
more
Contact Now

Add to Cart

Find Similar Videos
350mm 14 Inch Laser Welded Concrete Saw Blades For Circular Saw 00:14
350mm 14 Inch Laser Welded Concrete Saw Blades For Circular Saw
4inch Disco De Corte Para De Vidrio Diamond Glass Cutting Saw Balde Para Cortar Ceramic Porcelain Disc For Glass Ceramic 00:17
4inch Disco De Corte Para De Vidrio Diamond Glass Cutting Saw Balde Para Cortar Ceramic Porcelain Disc For Glass Ceramic
Vacuum Brazed Diamond Blade for Pipe 115mm Diamond blade Pro Pipe Cutter 00:24
Vacuum Brazed Diamond Blade for Pipe 115mm Diamond blade Pro Pipe Cutter
Demolition 5pcs Diamond Oscillating Multi Tool Saw Blades Curved 00:34
Demolition 5pcs Diamond Oscillating Multi Tool Saw Blades Curved
125mm Circular Wet Use Glass Ceramic Diamond Cutting Saw Blade 00:42
125mm Circular Wet Use Glass Ceramic Diamond Cutting Saw Blade
Turbo Cup 5 Inch 125mm Diamond Grinding Disc For Stone With M14 Thread 00:08
Turbo Cup 5 Inch 125mm Diamond Grinding Disc For Stone With M14 Thread
12 Inch 300mm Laser Welded Diamond Saw Blades For Cutting Hard Granite 00:31
12 Inch 300mm Laser Welded Diamond Saw Blades For Cutting Hard Granite
35mm Long Life Diamond Core Drill Bit For Drilling Granite / Hard Stone 01:41
35mm Long Life Diamond Core Drill Bit For Drilling Granite / Hard Stone
High Efficiency 110-230mm Diamond Saw Blades Sintered Hot Pressed Turbo Stone Cutting 00:09
High Efficiency 110-230mm Diamond Saw Blades Sintered Hot Pressed Turbo Stone Cutting
OD 600mm Diamond Saw Blades For Concrete , Reinforced Concrete And Asphalt 00:59
OD 600mm Diamond Saw Blades For Concrete , Reinforced Concrete And Asphalt
View Product Description

900mm Laser Welded Diamond Segmented Circular Saw Blade for Cutting Prestressed Concrete Hollow Slab

Description

Specially design for wet or dry cutting prestressed concrete, Hollow core concrete beds, Precast concrete etc.

Regular diameter size from 600-1500mm. At present, well exported 900mm, 1100mm, 1300mm to South africa, Bahrain, Vietnam, Egypt etc.

Feature

1) 100% laser welded technology.
2) Wet Cutting.
3) Fits to Precast Prestressed Concrete Machine-Bridge Crane, Prestressed concrete cutting machine.
4) Well exported to South africa, Bahrain, Vietnam, Egypt, UK, Thailand market.

Specification
Diameter:900mm
Segment thickness:6.5mm
Segment height:10/12/15mm
Inner hole:25.4mm, 50mm 60mm as your request

Inch Diameter
(mm)
Teeth length
(mm)
Teeth thickness
(mm)
Teeth height
(mm)
Teeth number
(nos)
36" 900 40 6.5 10 64
36" 900 40 6.5 12 64
36" 900 40 6.5 15 64


Other size Concrete Saw Blade we could do as following

Inch Diameter
(mm)
Teeth length
(mm)
Teeth thickness
(mm)
Teeth height
(mm)
Teeth number
(nos)
28" 600 40 4.4 15 42
28" 700 40 6.5 10/12/15 50
32" 800 40 6.5 10/12/15 57
40" 1000 40 7.0 10/12/15 70
44" 1100 40 7.5 10/12/15 74
48" 1200 40 8.0 10/12/15 80
52" 1300 40 8.0 10/12/15 88
56" 1400 40 9.0 10/12/15 95
60" 1500 40 9.0 10/12/15 100

Packing and Shipping

Each 5pcs 900mm laser welded prestressed concrete blades are packed in one plywood. Gross weight per plywood is limited within 105kg.

Shipping date: If there is steel discs in our stock, normally shipment within 7-10days. If not, around 25-30days.

Delivery way: By air, by sea, by land, by courier, etc.
