900mm Laser Welded Diamond Segmented Circular Saw Blade for Cutting Prestressed Concrete Hollow Slab
Description
Specially design for wet or dry cutting prestressed concrete, Hollow core concrete beds, Precast concrete etc.
Regular diameter size from 600-1500mm. At present, well exported 900mm, 1100mm, 1300mm to South africa, Bahrain, Vietnam, Egypt etc.
Feature
1) 100% laser welded technology.
2) Wet Cutting.
3) Fits to Precast Prestressed Concrete Machine-Bridge Crane, Prestressed concrete cutting machine.
4) Well exported to South africa, Bahrain, Vietnam, Egypt, UK, Thailand market.
Specification
Diameter:900mm
Segment thickness:6.5mm
Segment height:10/12/15mm
Inner hole:25.4mm, 50mm 60mm as your request
| Inch | Diameter (mm) | Teeth length (mm) | Teeth thickness (mm) | Teeth height (mm) | Teeth number (nos) |
| 36" | 900 | 40 | 6.5 | 10 | 64 |
| 36" | 900 | 40 | 6.5 | 12 | 64 |
| 36" | 900 | 40 | 6.5 | 15 | 64 |
Other size Concrete Saw Blade we could do as following
| Inch | Diameter (mm) | Teeth length (mm) | Teeth thickness (mm) | Teeth height (mm) | Teeth number (nos) |
| 28" | 600 | 40 | 4.4 | 15 | 42 |
| 28" | 700 | 40 | 6.5 | 10/12/15 | 50 |
| 32" | 800 | 40 | 6.5 | 10/12/15 | 57 |
| 40" | 1000 | 40 | 7.0 | 10/12/15 | 70 |
| 44" | 1100 | 40 | 7.5 | 10/12/15 | 74 |
| 48" | 1200 | 40 | 8.0 | 10/12/15 | 80 |
| 52" | 1300 | 40 | 8.0 | 10/12/15 | 88 |
| 56" | 1400 | 40 | 9.0 | 10/12/15 | 95 |
| 60" | 1500 | 40 | 9.0 | 10/12/15 | 100 |
Packing and Shipping
Each 5pcs 900mm laser welded prestressed concrete blades are packed in one plywood. Gross weight per plywood is limited within 105kg.
Shipping date: If there is steel discs in our stock, normally shipment within 7-10days. If not, around 25-30days.
Delivery way: By air, by sea, by land, by courier, etc.
